| Product number | specification | Conductor twisted outer diameter | Conductor resistance | Reference allowable current | Unshielded Complete outer diameter | Cable packaging |
| H05BZ-F | 3×1.5mm2+(0～6)×(0.5～1.0)mm2 | 1.6 | 13.3 | 10A | 8.6~9.6 | 800m/700# |
| 62893ICE121 | 3×2.5mm2+(0～6)×(0.5～1.0)mm2 | 2.1 | 7.98 | 16A | 9.8~10.8 | 800m/700# |
| H07BZ-F62893ICE123 | 3×1.5mm2+(0～6)×(0.5～1.0)mm2 | 1.6 | 13.3 | 10A | 8.8~9.6 | 800m/700# |
| 3×2.5mm2+(0～6)×(0.5～1.0)mm2 | 2.1 | 7.98 | 16A | 10~10.8 | 800m/700# | |
| 3×4.0mm2+(0～6)×(0.5～1.0)mm2 | 2.8 | 4.95 | 20A | 11.5 | 500m/700# | |
| 3×6.0mm2+(0～6)×(0.5～1.0)mm2 | 3.5 | 3.3 | 32A | 13.2 | 400m/800# | |
| 3×10.0mm2+(0～6)×(0.5～1.0)mm2 | 4.5 | 1.91 | 40A | 16.3 | 500m/950# | |
| 3×16mm2+(0～6)×(0.5～1.0)mm2 | 5.7 | 1.21 | 63A | 19 | 500m/700# | |
| 5×2.5mm2+(0～6)×(0.5～1.0)mm2 | 2.1 | 7.98 | 16A | 13.5 | 500m/950# | |
| 5×4.0mm2+(0～6)×(0.5～1.0)mm2 | 2.8 | 4.95 | 20A | 15 | 400m/950# | |
| 5×6.0mm2+(0～6)×(0.5～1.0)mm2 | 3.5 | 3.3 | 32A | 16.8 | 300m/950# | |
| 5×10.0mm2+(0～6)×(0.5～1.0)mm2 | 4.5 | 1.91 | 40A | 20 | 300m/1200# | |
| 5×16mm2+(0～6)×(0.5～1.0)mm2 | 5.7 | 1.21 | 63A | 23.5 | 800m/700# | |
| 5×25mm2+(0～6)×(0.5～1.0)mm2 | 7.2 | 0.78 | 80A | 29 | 800m/700# | |
| 5×35mm2+(0～6)×(0.5～1.0)mm2 | 8.4 | 0.554 | 125A | 32.8 | 500m/700# |
